Unigraf UCD-422: 8K video analyzer and generator

The UCD-422 is a video generator and analyzer for testing the HDMI 2.1 interface up to 8K video modes. Resolutions up to 8K@60 fps are supported. The UCD-422 offers support for FEC, DSC Sink & Source and aARC. HDCP 2.2 and HDCP 2.3 are also supported. UCD-422 is a flexible and robust tool either via an easy-to-use GUI for R&D debugging or via automated functional tests. UCD Console GUI provides the user access to the vital test parameters and controls.

Dolby Vision™ Test Tool

UCD-422 is an official Dolby Vision™ test tool. Unigraf provides video and audio capturing via the UCD-422. The UCD Console GUI provided with the UCD-422 shows the video capture. Dolby provides customers with the software package that analyzes the Dolby Vision™ video captured with the UCD-422.

Highlights

• HDMI 2.1 test equipment (FRL)
  • Enhanced gaming features (VRR, ALLM)
  • Forward Error Correction (FEC)
  • HDCP 2.2 & HDCP 2.3 support
  • TMDS support
  • Dolby Vision™ test tool
  • 8K@60 fps support (12 Gbps/channel)
  • eARC support
  • DSC support (expected in 2020)
  • UCD Console GUI for debugging
  • High-level API for easy integration
• Video analyzer software (expected in Q1 2020)

About Unigraf

Unigraf is a world-leading video electronics testing company that specializes in hardware and software test tools for testing USB-C™, DisplayPort™ and HDMI™ interfaces. Unigraf’s technological strengths are its deep understanding of the interfaces in R&D, test automation and compliance test environments. Unigraf has introduced multiple ground-breaking innovations.

More information

For more information about Unigraf and its product line, please contact us.

Ultra-high-performance EMC test equipment and advanced EMI test solutions

ACA TMetrix is pleased to announce that we now have a new supplier—Gauss Instruments, a Germany-based manufacturer of ultra-high-performance EMC test equipment and provider of advanced EMI test solutions that:

• Rapidly advance product development and testing capabilities;
• Accelerate time-to-market cycles.

Product certification and precertification

Since its foundation in 2007 Gauss Instruments has been putting the turbo in EMC, making product certifications and precertification tasks simpler than they’ve ever been. All around the world Gauss Instruments provides unrivaled products, advanced test solutions, and services— in conjunction with a local service partner.

Receiver and analyzer solutions

Gauss Instruments’ ongoing innovation combines its deep knowledge of real-time digital signal processing, millimeter, and microwave technologies to develop receiver and analyzer solutions that combine and blur the lines between previously discrete test instruments—while delivering speeds and analysis capabilities several orders of magnitude greater than other measurement equipment. Combining both the advantages of the ‘old’ analog and the ‘new’ digital world, Gauss pushes your testing to the next level—and readies it for the future.

More information

For more information about Gauss Instruments and its product line, please contact us.
